ACB 1600Amp/4-Pole Air Circuit Breaker – Draw-Out
ACB1600/4P is an air circuit breaker (ACB), rated 1600 A with 4 poles for high-current distribution.
About this part
Air circuit breakers protect the largest circuits in an installation, typically the main incomer or a large generator. The draw-out design lets the breaker be racked out of its cradle for maintenance or isolation without disconnecting the busbars.
Features
- 1600 Amp
- 4 Pole
- 3 phase
- Single ground protect function.
When to replace it
- New main switchboard
- Large generator installation
- Replacing an old incomer breaker
Before you order
ACBs are specified by a qualified electrician or engineer to suit the fault level and protection settings of the installation. Send us the specification and we will quote.
Match the number stamped on the part you are removing, or the number in your engine or alternator manual, before ordering. Part numbers are shown for reference so the right replacement can be identified.
Questions
What does draw-out mean?
The breaker sits in a cradle and can be withdrawn for testing or maintenance without disconnecting the busbars.
Specifications
| Part number | ACB1600/4P |
|---|---|
| Brand | IEP Powerproducts |
| Range | Air Circuit Breakers |
| Current rating | 1600 A |
| Poles | 4 |
| Mounting | Draw-out |
| Working Voltage | AC400/AC690, 50Hz |
| Intelligence controller | H (intelligence type), M (Standard type), L (Economy type) |
| Alarm function | overload alarm |
| Self test function | overheating self test, microcomputer self diagnosis |
| Test function | intelligent controller of operating characteristic |
Not sure it fits?
Send us the number on your old part, or a photo with the engine or alternator nameplate, and we'll confirm the match.
